H6F

Type: Single Point

Material: Nickel plated alloy steel

Ingress Protection: IP66

Capacities: 100kg, 150kg, 200kg, 250kg, 350kg, 500kg, 750kg, 1000kg, 2000kg

Output Sensitivity: 2.0mV/V

Input Resistance: 384 ± 4Ω

Output Resistance: 350 ± 2Ω

Color coding:
Excitation (+): Red
Excitation (-): Black
Signal (+): Blue
Signal (-): White
Sense (+): Brown
Sense (-): Yellow
